Modern .NET Backend Roadmap — Part 8: CI/CD with GitHub Actions

Every manual deployment is a small bet that you'll remember all the steps, in order, under pressure. CI/CD replaces that bet with a pipeline: every push builds, tests, and packages the same way; releases become boring. This part wires GitHub Actions for the roadmap API — a CI workflow that builds, smoke-tests, and produces the Docker image, then the deploy job that ships it to Azure from part 7.

The CI workflow

.github/workflows/ci.yml in the repository root:

name: ci

on:
  push:
    branches: [master]
  pull_request:

jobs:
  build-test:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Setup .NET
        uses: actions/setup-dotnet@v4
        with:
          dotnet-version: 10.0.x

      - name: Restore
        run: dotnet restore

      - name: Build
        run: dotnet build --no-restore -c Release

      - name: Smoke test the API
        run: |
          dotnet run --project src/Roadmap.Api -c Release --no-build &
          sleep 8
          curl -sf http://localhost:5152/products | grep "Mechanical keyboard"

      - name: Docker image
        run: docker build -t roadmap-api .

Design notes:

• pull_request + push triggers — PRs get the full check before merge; master gets it again on the real merge commit.
• A smoke test beats no test. Unit tests belong here too (dotnet test), but even this curl — boot the app, hit an endpoint, assert on the payload — catches the "builds fine, crashes on startup" class that unit tests miss. It exercises DI registration, EF model building, and seeding in one line.
• The Docker build runs in CI even before you deploy from CI, because part 6 taught us image builds fail for environment reasons (.dockerignore, restore state). Find out on the runner, not on release day.

One practical note from setting this up: pushing workflow files requires an OAuth token with the workflow scope — if your gh login predates that scope, gh auth refresh -h github.com -s workflow fixes the 403.

Adding the deploy job

Deployment extends the same file. The modern way to let GitHub talk to Azure is OpenID Connect federation — no long-lived password stored in GitHub at all; Azure trusts tokens GitHub mints per run:

  deploy:
    needs: build-test
    if: github.ref == 'refs/heads/master'
    runs-on: ubuntu-latest
    permissions:
      id-token: write
      contents: read
    steps:
      - uses: actions/checkout@v4

      - uses: azure/login@v2
        with:
          client-id: ${{ secrets.AZURE_CLIENT_ID }}
          tenant-id: ${{ secrets.AZURE_TENANT_ID }}
          subscription-id: ${{ secrets.AZURE_SUBSCRIPTION_ID }}

      - name: Build and push image
        run: az acr build --registry roadmapacr --image roadmap-api:${{ github.sha }} .

      - name: Deploy revision
        run: |
          az containerapp update --name roadmap-api --resource-group roadmap-rg \
            --image roadmapacr.azurecr.io/roadmap-api:${{ github.sha }}

The load-bearing details:

• needs: build-test + the branch if — deploys only happen for master commits that passed CI. PRs build; they never deploy.
• github.sha as the image tag. Every deployment maps to exactly one commit. "What's running in prod?" becomes az containerapp show + git show. Never deploy :latest — it's a tag that answers no questions.
• The three AZURE_* values are identifiers, not secrets (client/tenant/subscription IDs); the trust lives in the federated credential you create once on an Entra app registration, scoped to this repo and branch.

Rollback falls out for free: redeploy the previous SHA, or shift traffic to the previous Container Apps revision.

Environments and approvals

GitHub Environments add the governance layer when you need it: attach the deploy job to environment: production, and you can require a human approval click, restrict which branches may target it, and scope secrets per environment. A staging job deploying automatically + a production job requiring approval is the 80% pattern:

    environment: production   # approval rules configured in repo settings

Real tests in the pipeline

The smoke test guards startup; unit and integration tests guard behavior. The fuller job most teams converge on:

      - name: Unit tests
        run: dotnet test tests/Roadmap.UnitTests -c Release --no-build --logger trx

      - name: Integration tests
        run: dotnet test tests/Roadmap.IntegrationTests -c Release --no-build
        env:
          ConnectionStrings__Default: "Host=localhost;Database=roadmap_test;Username=postgres;Password=postgres"

with a service container supplying the database:

    services:
      postgres:
        image: postgres:16
        env: { POSTGRES_PASSWORD: postgres, POSTGRES_DB: roadmap_test }
        ports: ["5432:5432"]
        options: >-
          --health-cmd pg_isready --health-interval 5s --health-retries 10

Because part 1 made the domain and application layers infrastructure-free, the unit-test job needs nothing but the runner — it finishes in seconds and gates every PR. The integration job runs real EF migrations and Dapper SQL against disposable Postgres; slower, but it's the only thing that catches a renamed column before production does. Publish results with dorny/test-reporter so failures annotate the PR diff instead of hiding in logs.

When the pipeline fails: debugging CI

CI failures split into three families, each with a fast diagnostic:

• Fails in CI, passes locally. Almost always environment: a file the runner doesn't have (check .gitignore against what the build needs), case-sensitive paths (Linux runners care; macOS doesn't — our GeeksArray.Ats vs GeeksArray.ATS casing bug shipped exactly this way), or a missing env var. git clean -xdf && dotnet build locally reproduces most of them.
• Flaky. Timing-dependent tests, port collisions, external calls. Quarantine the test the day it first flakes — a suite people re-run on red is a suite nobody trusts, and its signal is already gone.
• Slow creep. Pipelines gain steps and lose minutes. Budget it like a feature: cache restore, split jobs to run in parallel, and alert when total time crosses your threshold (10 minutes is a good line for a service this size).

gh run view --log-failed pulls just the failing step's log to your terminal — faster than clicking through the web UI, and scriptable when you're fixing a red main branch under pressure.

Pipeline hygiene that pays compound interest

• Cache NuGet (actions/setup-dotnet with cache: true) — restore drops from minutes to seconds.
• Fail fast, fail loud. curl -sf (the -f) makes non-2xx responses fail the step; without it your smoke test is decorative.
• Keep the workflow in the repo, reviewed like code — it is the release process, and PR review is your change-management.
• Concurrency guards (concurrency: production-deploy) stop two merges racing each other mid-deploy.

Database migrations in the pipeline

The step everyone defers: schema changes must ship with code changes, safely. Three workable strategies, in order of increasing rigor:

1. Migrate on startup (db.Database.Migrate() behind a flag) — fine for single-replica apps; dangerous with multiple replicas racing to migrate. If you use it, gate it so only one instance runs migrations (an init job, or a startup lock table).
2. A migration job in the pipeline — the deploy job runs dotnet ef database update (or applies an idempotent SQL script generated by dotnet ef migrations script --idempotent) before swapping traffic to the new revision. The script variant is auditable and doesn't need the SDK on the target.
3. Expand–contract for zero-downtime — additive migration first (new nullable column), deploy code that writes both, backfill, then a later contract migration removes the old shape. This is the only strategy that survives rolling deployments where old and new code briefly coexist — which, with Container Apps revisions, is every deployment.

Whichever you choose, one rule is absolute: the pipeline, not a human with a connection string, applies production schema changes. The migration script in the artifact + the SHA-tagged image means any environment can be reconstructed to a known pair of (code, schema) — which is what turns "the deploy broke" from archaeology into a diff.

The goal state is cultural, not technical: deploys stop being events. geeksarray.com ships this way — a push builds the image on the server and swaps the container; publishing a code change and publishing a blog post are comparably dull.

Next

One well-shipped service is the right place to pause and ask the uncomfortable question: should it become several? Part 9 tackles microservices — what they buy, what they cost, and why the modular monolith we've been building is the best launchpad either way.
